AD9850/AD9851 DDS Signal Generator Module 2 Sine Wave 2 Square Wave Output

AD9850/AD9851 DDS Signal Generator Module 2 Sine Wave 2 Square Wave Output

SKU:010169
Regular price $25.99 USD Sale price $18.99 USD



Specification:

  • AD9850: 0-40MHz.
  • 2 sine wave and 2 square wave output.
  • After the 20-30MHz frequency harmonics increases, the waveform will be less and less clean.
  • Square Wave: 0-1MHz.
  • Low-pass filter with 70MHz, so the waveform better than SN.
  • Parallel and serial data input can be selected via a jumper.
  • DA produced the benchmark pin (PIN12) leads for easy adjustment to do the magnitude of the output waveform Application.
  • Comparator reference input voltage generated by the variable resistor, the resistor can be adjusted duty cycle square wave of different.
  • Active AD9850 125MHz crystal oscillator modules.
  • Dimension:4.5cm x 2.6cm





 Package:

  • 1 X AD9850 DDS Signal Generator Module 0-40MHz Test Equipment
