CBB60 10UF 400-500VaH Run Motor Capacitor Compressor Air conditioning Water Pump

Cbb60 450V 10Uf 20Uf 30Uf 40Uf 60Uf Polypropylene Film Start Capacitor Ac Motor Run Capacitors 400

CBB60 10UF 400-500VaH Run Motor Capacitor Compressor Air conditioning Water Pump

SKU:X52733
Regular price $7.99

Description:


CBB60 polypropylene film capacitor

1. Shell: ABS, polypropylene,

2. Features and uses: The product has good stability, high impact current resistance, strong overload capability, low loss, high insulation resistance, long rated working life, excellent self-healing performance, safe and reliable built-in flame retardant epoxy resin filling, capacitor Non-toxic, non-leaking and liquid materials, which are good for environmental protection. Mainly used in refrigerators, air conditioners, AC motors, pumps, generators, washing machines, household appliances, electronic products, etc.

3. Technical parameters:
Capacity range: 10 μ F to 80 μ F
Capacity deviation: +/- 5%
Rated voltage: 400V ~ 500VAC, 50 / 60Hz
Operating temperature range: -25°C to +70°C
Withstand voltage between terminals: AC >= 1.75Un 5S without breakdown
Withstand voltage between the terminal and the outer casing: AC >= 2000V 10S without breakdown
Insulation resistance: Rj . C >= 3000M Ω between the terminals. μ F; Rj >= 1000M Ω between the terminal and the shell

CBB capacitors are metallized polypropylene film series structure type, which can resist high voltage and high current impact.

CBB60 capacitor is suitable for starting and running one-way motor with 50Hz (60 HZ) AC power supply. It has the characteristics of small size, light weight, low price, low loss and good self-healing effect.
