CC/CV Adjustable 5A Step Down Charge LED Panel Voltmeter Ammeter Display Module Red Red/ Red Blue
SKU:010376
Regular price
$9.99 USD
![]()
- guaranteeQuality checked
- Special gift cardsSpecial gift cards
- Free return Within 60 days
- Consultancy86-0755-85201155
Specification:
Package Included:
1 x Red+Blue/Red+Red 5A Step Down Charge Module
- Universal receiver.
- Module Properties: non-isolated constant current and voltage module
- Rectification: non-synchronous rectification
- Input voltage: 5V-30V
- Output voltage: 0.8V-28V/0.1A-5A
- Output current: adjustable maximum 5A
- Conversion efficiency: 95% (the highest)
- Switching frequency: 300KHz
- Output ripple: 50mV (max) 20M bandwidth
- Load Regulation: ± 0.5%
- Voltage Regulation: ± 2.5%
- Operating Temperature: -40℃~ +85℃
- Voltmeter Ammeter:
- Measurement accuracy: 0.1%
- Refresh rate: about 200ms/times
- Display: 0.28" digital tube
- Current Range 0.1A-5A
- Voltage range 5V-30V
- Display Color: Red+Blue/Red+Red
Package Included:
1 x Red+Blue/Red+Red 5A Step Down Charge Module
