Durable DL-CT08CL5-20A 10mA 2000 1 0~120A Micro Current Transformer
Durable DL-CT08CL5-20A 10mA 2000 1 0~120A Micro Current Transformer
SKU:011192
Regular price
$5.99
![]()
- guaranteeQuality checked
- Special gift cardsSpecial gift cards
- Free return Within 60 days
- Consultancy86-0755-85201155
Description:
- 100% brand new and high quality
- The main technical parameters:
- Rated Input Current: 0 ~ 20A
- Rated Output Current: 0 ~ 10mA
- Error Ratio (f): ≤ ± 0.1%
- Phase Shift (Φ): ≤10 '
- Accuracy: 0.1
- Compressive Strength: ≥4KV
- Chang-current: 0 ~ 80A (long-term operating current of less than 80A)
- Linear Protection Current: 0 ~ 120A
- Usage: When the primary current from P1 through the transformer secondary winding current flowing into the external
- circuit from S1
- Application Range: 60A following meter dedicated; 0 ~ 80A single-phase / three-phase current detection; 0 ~ 120A
- single-phase / three-phase motor protection
- Zero sequence / drain / remaining capacity detection and monitoring
- 1 x DL-CT08CL5 20A/10mA 2000/1 0~120A Micro Current Transformer
