XL4016 PWM 4-38V To 1.25-36V Adjustable Step-Down Board Module DC-DC Converter
XL4016 PWM 4-38V To 1.25-36V Adjustable Step-Down Board Module DC-DC Converter
SKU:012525
Regular price
$5.99
![]()
- guaranteeQuality checked
- Special gift cardsSpecial gift cards
- Free return Within 60 days
- Consultancy86-0755-85201155
Description:
- Product name: DC voltage regulator
- Voltage regulating mode: PWM modulation
- Input voltage: DC 4-38V
- Output voltage: DC 1.25-36V
- Maximum current: 8A(please add fan and make current less than 5A for a long term use)
- Maximum power: 200W
- Conversion efficiency: 95%
- Switching frequency: 180KHz
- Working Temperature: -45~+85℃
- Size: 6x3.7cm/2.36x1.46inch
Features:
The voltage regulator has excellent linearity regulation and load regulation
With multiple protection: over-current protection, over-temperature protection and short circuit protection, etc
Wide Application:
Car audio, radio, navigator, monitor, LED car display, air conditioner, interphone, motors etc
Note:
Please make sure there is a 2V voltage difference between input voltage and output voltage
The maximum output current can reach 8A; For long time working please make sure the current is less than 5A.
This is not a step up module, but a step down module
Package Included:
1 x Step-Down Board
